PLB HDPE DUCT PIPE

Western is INDIA’S 4th Company with Approved TEC Certification PLB HDPE Telecom Duct Pipes With 8 Colors and from 32mm to 110mm.

PLB_01

PLB HDPE TELECOM DUCT PIPE - TEC GR No.
TEC/GR/FA/CDS-008/04. AUG 19

AS PER RDSO SPECIFICATION NO. RDSO/SPN/TC/45/2013.

CUSTOMIZATION AS PER CLIENT REQUIREMENT

PLB HDPE Duct Pipe
PLB Duct Pipe Image
Pipe Available In Colors
PLB_02
Key Features
PLB_01

100% Virgin Raw Plastic Pulp Material.

PLB_02

Flexibility And Crush Resistance.

PLB_03

Hydrostatic Strength And Durability

PLB_04

Chemical Resistance.

PLB_05

Elastic Suitable

PLB_06

UV Resistant & Poor Heat Conductivity

PLB_07

Non Toxic

PLB_08

Wear Resistant

PLB Duct Pipe Image
PLB Duct Pipe Image
PLB Duct Pipe Image
Plb HDPE Duct Pipe Size Chart
32 mm/26 mm40 mm /33 mm50 mm/42 mm63mm/50 mm110mm/80 mm
Outside diameter32 mm + 0.3 mm – 0.0 mm40 mm + 0.4 mm – 0.0 mm50 mm + 0.5 mm – 0.0 mm63 mm + 0.6 mm – 0.0 mm110 mm + 1.0 mm – 0.0 mm
Wall thickness3.0 mm ± 0.2 mm3.5 mm ± 0.2 mm4 mm ± 0.3 mm6.5 mm ± 0.40 mm15.0 mm ± 0.60 mm
Thickness of the Inner LayerMinimum: 0.24mm Maximum: 0.36mmMinimum: 0.28 mm Maximum: 0.42 mmMinimum: 0.32 mm Maximum: 0.48 mmMinimum: 0.36 mm Maximum: 0.54 mmMinimum: 0.56 mm Maximum: 0.84 mm
Standard length1000 ± 100 meters1000 ± 100 meters1000 ± 100 meters500 ± 50 meters200 meters ± 20 meters.
Maximum outer diameter of OF cable that can be installed by blowing technique.12 mm16 mm21 mm25 mm (144 fibres)40 mm (576 fibres)
